For friends who want to make their own toroid transformer, you can use the "Calculate Toroidal Transformer" application. This application can be downloaded directly on the play store.
Or you can scan this QR Code :
The menu on the main page of this application:
1. Manual Ampere
In this section we can determine:
- Maximum power of transformer Kern
- Primary and secondary power
- Primary and secondary current
- Coils per Volt
- Number of primary and secondary turns
- Required length of primary and secondary winding
- Weight of primary and secondary winding required
By entering the input:
- He meters outside kern
- Kern dalam inner diameter
- Kern Tinggi Height
- Secondary Voltage
- Secondary Current
2. Auto Ampere
In this section we can determine:
- Maximum power of transformer Kern
- Primary and secondary power
- Primary and secondary current
- Coils per Volt
- Number of primary and secondary turns
- Required length of primary and secondary winding
- Weight of primary and secondary winding required
By entering the input:
- He meters outside kern
- Kern dalam inner diameter
- Kern Tinggi Height
- Secondary Voltage
3. Kern formula
In this section we can determine:
- Maximum power of transformer Kern
- Kern Weight
By entering the input:
- He meters outside kern
- Kern dalam inner diameter
- Kern Tinggi Height
4. Cable Weight Formula
In this section we can determine:
- Cable Weight
By entering the input:
- Winding length
- Winding diameter
- Type of winding material
5. Current Formula
In this section we can determine:
- Required Transformer Kern Weight
- Primary and Secondary Current
- Primary and secondary power
- Diameter of primary and secondary winding
By entering the input:
- Desired transformer secondary current
- Desired secondary voltage
- Primary voltage.
6. Power Formula
In this section we can determine:
- Maximum power of transformer Kern
- Kern Weight
By entering the input:
- Transformer primary and secondary power
Enough of the discussion about the Calculate Toroidal Transformer application. Hopefully useful, and if there are mistakes I apologize. Thank you...
